Per the Instructions for Use, physicians should prepare the vessel using standard angioplasty technique; balloon size should be greater than or equal to the stent diameter. Refer to the IFU for additional information.
| Labelled Stent Diameter | Reference Vessel Diameter | Nominal Stent Length (mm) | Catheter Outer Sheath Diameter |
|---|---|---|---|
| 4.5 mm | 4.0 - 4.5 mm | 20, 30, 40, 60, 80, 100, 120, 150 | 6F 2.06 0.081 inches |
| 5.5 mm | 5.0 - 5.5 mm | 20, 30, 40, 60, 80, 100, 120, 150, 180, 200 | |
| 6.5 mm | 6.0 - 6.5 mm | 20, 30, 40, 60, 80, 100, 120, 150, 180, 200 | |
| 7.5 mm | 7.0 - 7.5 mm | 20, 30, 40, 60, 80, 100 |
** 20 and 30 mm lengths available in 120 cm catheter lengths only.
The image below is a percutaneous transluminal angioplasty (PTA) balloon inflation example for a 5.5 mm Supera™ Stent.
Precaution: The vessel/duct after pre-dilatation should be at least the size of the stent diameter. If recommended, vessel/duct diameter cannot be gained, optimal stent deployment may not be achieved and revised stent sizing should be considered.
MAT-2409321 v1.0
